Beta Zeolite Molecular Sieve

Min.Order / FOB Price:Get Latest Price

500 Kilogram	FOB Price:USD 5.5500 -5.8500

500 Kilogram

FOB Price:USD 5.5500 -5.8500

Min.Order :500 Kilogram
Purity: 95%
Payment Terms : L/C,T/T

Keywords

Beta Zeolite Molecular Sieve Zeolite Molecular Sieve CAS NO.1318-02-1

Quick Details

Appearance:White Powder
Application:High Hydrocracking Beta Zeolite Molecular Sieve Catalyst Powder with Excellent Activity / Selectivity The Beta zeolite produced by means of a template agent based hydrothermal crystallization method
PackAge:25kg/woven bag, 500kg/palle by the customer requirement
ProductionCapacity:120|Metric Ton|Day
Storage:Place at room temperature
Transportation:FOB/CFR/CIF BY SEA

Superiority:

Beta Zeolite Molecular Sieve

Beta zeolite,having a unique three-dimensional 12-membered ring cross channel structure,is composed by mixing two polycrystals which are closely related to each other in the structure,and the two polycrystals are composed of the tetrahedral structure units which are symmetric based on the same center and arranged according to the layer.The two structures are composed of the tertiary structure units(TBU)which are symmetric based on the same center,wherein these TBUs are arranged in layer and subsequently connected in the form of left hand and right hand,This connection causes the twist along the channel of the direction C.

Beta zeolite shows an excellent catalytic performance in catalytic cracking,hydrocracking,hydroisomerization,hydrodewaxing,aromatics alkylation,olefin hydration,olefin etherification and other petroleum refining and petrochemical processes.

The varieties for the typical products of Beta Zeolite produced by JiuLong Chemical Co.,Ltd.are listed as follows,and the other products of this series also can be produced according to the requirements of the user:

Details:

Beta Zeolite Molecular Sieve

Beta-25 Zeolite

The Beta zeolite produced by means of a template agent based hydrothermal crystallization method is featured with high relative crystallinity,wherein the relative crystallinity is no less than 78%,the SiO₂/Al₂O₃ molar ratio is no less than 23,the Na₂O is no more than 0.1%,and the BET specific surface is no less than 500m²/g

Beta-25 Quality Control Targets

Item	Unit	Max	Typical	Max	Analytical Method
Relative crystallinity	%	76	80		X-ray diffractometer
Crystal size	nm	50	70
Total specific surface	M²/g	500	540		N₂Adsorption
Microporous specific surface	M²/g	430	460		N₂Adsorption
Pore Volume	mL/g	0.30	0.32		N₂Adsorption
Silica-alumina ratio	/	23	25	27	XRF
Na₂O	wt%			0.1	Flame Photometric Analysis
SO₄²-	wt%			0.4	XRF
CI	wt%			0.2	Chemical Analysis
LOI	wt%			15	Gravimetric Analysis
