Synthetic Mordenite Molecular Sieve as Catalyst for Petrochemical Industry
Synthetic Mordenite Molecular Sieve as Catalyst for Petrochemical Industry
Synthetic Mordenite Molecular Sieve as Catalyst for Petrochemical Industry

Synthetic Mordenite Molecular Sieve as Catalyst for Petrochemical Industry

Min.Order / FOB Price:Get Latest Price

500 Kilogram

FOB Price:USD 4.4500 -4.8900
  • Min.Order :500 Kilogram
  • Purity: 93%
  • Payment Terms : L/C,T/T

Keywords

Zeolite Molecular Sieve Catalyst Mordenite Molecular Sieve Synthetic Mordenite Molecular Sieve

Quick Details

  • Appearance:White Powder
  • Application:ZSM-5 type zeolite is widely applied to petrochemical processing industries,applied to the fluidifying,catalyzing and cracking process as an assistant for producing more propylene and liquefied gas,an
  • PackAge:25kg/woven bag, 500kg/palle by the customer requirement
  • ProductionCapacity:100|Metric Ton|Day
  • Storage:Place at room temperature
  • Transportation:FOB/CFR/CIF BY SEA

Superiority:

Synthetic Mordenite Molecular Sieve as Catalyst for Petrochemical Industry
Detailed Product Description
SiO2/Al2O3: 18,30,40,50,60.80.100.120.140.160.180 Color: White Powder
Cation: Hydrogen SiO2/Al203: 240
SIO2/AL2O3: Dealuminate D50: 7um
D90: 9um






SiO2/Al2O3 Mole Ratio: 30-240
Nominal Cation Form: Sodium/Hydrogen
Na2O %:0.05
Surface Area, m2/g: 425

Products SiO2/Al2O3Mole Ratio Nominal Cation Form Na2O % Surface Area, m2/g
30 30 H 0.05 425
40 40 H 0.05

425







Introduction:



White, odorless, powder. May cause skin irritation and mild eye irritation. Prolonged or repeated contact may dry skin and cause irritation. Wear safety goggles, body-covering protective clothing, chemical resistant gloves, and rubber boots.



Application:



Mordenite’s molecular structure is a framework containing chains of five-membered rings of linked silicate and aluminate tetrahedra. The mordenite zeolite high ratio of silicon to aluminum atoms makes it more resistant to attack by acids than most other zeolites. Synthetic Mordenite is used as a catalyst in the petrochemical industry for the acid-catalyzed isomerisation of alkanes and aromatics.







Synthetic Mordenite Molecular Sieve As Catalyst For Petrochemical Industry



Details:

                         Synthetic Mordenite Molecular Sieve as Catalyst for Petrochemical Industry

The ZSM-5 type zeolite produced by means of a template agent free hydrothermal crystallization method is featured with high relative crystallinity,wherein the relative  crystallinity is no less than 90%,the SiO2/Al2O3 molar ration is no less than 25,and the Na2O is no more than 0.1%.

ZSM-5 Quality Control Targets

Item
Unit
Max
Typical
Max
Analytical Method
Relative crystallinity
%
90
93

X-ray diffractometer
Total specific surface
m2/g
320
360

N2 Adsorption
Microporous specific surface
m2/g
270
280

N2 Adsorption
Silica-alumina ratio
/
25
27.5
30
XRF
Na2O
wt%

0.040
0.1
Flame Photometric Analysis
SO42-
wt%

0.20
0.4
XRF
CI-
ppm


70
Chemical Analysis
LOI
wt%


10
Gravimetric Analysis
D,50
μm

6
9
Laser Scatter Distribution
D,90
μm

9.0
15
Laser Scatter Distribution
>100μm
%

0
0.06
Laser Scatter Distribution

   Introduction:



White, odorless, powder. May cause skin irritation and mild eye irritation. Prolonged or repeated contact may dry skin and cause irritation. Wear safety goggles, body-covering protective clothing, chemical resistant gloves, and rubber boots.



Application:



Mordenite’s molecular structure is a framework containing chains of five-membered rings of linked silicate and aluminate tetrahedra. The mordenite zeolite high ratio of silicon to aluminum atoms makes it more resistant to attack by acids than most other zeolites. Synthetic Mordenite is used as a catalyst in the petrochemical industry for the acid-catalyzed isomerisation of alkanes and aromatics.







Synthetic Mordenite Molecular Sieve As Catalyst For Petrochemical Industry
